Clamp fitting - for copper pipe, 18 x 1 - EK
Code: 500417Related products
Product detailed description
Fasteners - for copper pipe, IVAR.TR 4430, size: 18 x 1 - EK, packing: 40 pcs in bag / 320 pcs in box
- PN 10, T = +120 °C
- Eurocone (EC) wrap
- use for Cu and IVAR piping.C-STEEL
- material brass CW617N, O-ring - EPDM
- tightening torque 35–45 Nm for Cu wiring
- tightening torque 40-50 Nm for IVAR wiring.C-STEEL
To properly install the clamp fitting, follow these instructions:
1. Install the clamp fitting in the sequence and snow as indicated in the following figures.
2. Insert the pipe and the appropriate EPDM gasket into the fitting and ensure that everything is clean and that there is no damage to the O-ring.
3. Fit the nut onto the thread and hand tighten, use the appropriate size AC 670 / AC 671 spanner to fully tighten
The rubber parts must not be lubricated with mineral oils under any circumstances, only silicone based lubricant should be used on the EPDM material.
No lubricant should be used on the EPDM material.
Additional parameters
Category: | clamp fitting for Cu pipe |
---|---|
Warranty: | 2 roky |
Weight: | 0.048 kg |
